Drum Magnification: 10X, 16X, 25X
Parallel type, Galilean system
Superior optic quality, provides stereoscopic and comfortable view
With broad beam, wild field and high depth of field
Warm LED Illumination, Better Conformity, Longer Life Time
Work 50 thousand hours,and suitable for human tissue.
Precision Machining Makes Smooth and Flexible Movement
Brightness Control Continuously
Interface for laser and applanation tonometer reserved
| Optical Part | |
| Microscope Type | Galilean Type System |
| Magnification Changer | Revolving Drum |
| Magnification | 10X,16X,25X |
| Eyepiece Magnification | 12.5x |
| Visual Angle of Eyepiece | 13° |
| PD Range | 52mm-85mm |
| Diopter | ±7D |
| Visual Field Diameter | 10X(22mm),16X(14mm), 25X(8.5mm) |
| Illumination Part | |
| Illumination Type | Tower Type |
| Light Source | Warm LED |
| Brightless control | Continuously adjustable |
| Illumination tilting | 5°,10°,15°,20° |
| Slit Width | 0mm-14mm continuously adjustable |
| Slit Height | 1mm-14mm continuously adjustable |
| Slit Angle | 0°~180°continuously adjustable |
| Slit Aperture Size | Φ0.2，Φ1，Φ3，Φ5，Φ10，Φ14（mm) |
| Filter | Heat Aborption, Grey, Redfree(Green), Cobalt Blue |
| * Voltage: 100~240V 48~62Hz Compatible | |
